The Belle Internal Circlip 38 x 1.6 (OEM 3/9023) is a replacement retaining ring used within the gearbox and spider assembly of compatible Belle power trowels. It fits into an internal groove to securely retain associated components within the assembly, helping prevent unwanted axial movement during operation.

Designed for the demanding conditions of concrete finishing equipment, the circlip provides a secure mechanical retaining solution within the power trowel drivetrain. It is used in conjunction with the spider arm and gearbox components, where reliable retention is important to maintain correct assembly and operation. Belle parts information identifies 3/9023 as an internal 38 x 1.6 mm circlip, with one required in the applicable assembly.

FUNCTION AND OPERATION

Retains components within the Belle power trowel gearbox and spider assembly.
Fits into an internal machined groove to provide secure axial retention.
Helps prevent associated components from moving out of position during operation.
Supports correct positioning of the spider and gearbox components.
Replaces a worn, damaged or missing original circlip.

TECHNICAL DETAILS

Brand: Belle
OEM Number: 3/9023
Part Type: Internal circlip
Size: 38 x 1.6 mm
Application: Belle power trowels
Assembly: Gearbox and spider assembly
Quantity: 1

TYPICAL APPLICATIONS

Belle PT Range Pro power trowels
Belle Pro Tilt power trowels
Belle Lightweight Pro power trowels
Compatible 900 and 1200 power trowel assemblies
Gearbox and spider assemblies

IMPORTANT INFORMATION

The internal circlip is a small but important retaining component within the power trowel drivetrain. A damaged, distorted or incorrectly fitted circlip can allow unwanted movement of the retained components, so it should be replaced if its retaining function has been compromised.

Always check the OEM number and power trowel model before ordering to ensure the correct replacement circlip is selected. The circlip is supplied as an individual component and is listed as quantity one in the applicable gearbox and spider assembly.

Pack quantity	1
Weight	0.02
OEM Number	3/9023
Manufacturer	Belle

Available as part of:

Belle Lightweight / Pro Tilt Gearbox & Spider
